Description
An automatic filling machine guides, organizes, fills, and then releases bottles in an automatic bottle packaging line, such as a filling, capping, and labeling line. They can be programmed to reliably fill each bottle with a specified and precise volume of product and remove the necessity for an operator in the filling line. With an accuracy of ±0.5%, Kinex automatic filling machines fill bottles quickly and precisely. They can fill a wide variety of products, from light liquids to thick liquids with a viscosity up to 3000 centipoise (cP).
Our automated liquid fillers are designed to provide customers with a flexible and easy to adjust automatic bottle filling machine, resulting in fast changeover times. The pumps on our automatic filling machines contact only the exterior of the filling tube and never come in contact with the product. As a result, cleanup is fast, worry free, and the potential for cross contamination is eliminated. Available in configurations of 1 – 8 filling heads, you will find an automated bottle filling machine suitable for your filling lines.
Automatic filling machines are used in the food and beverage industry, pharmaceutical industry, chemical industry, e-liquid industry, and many more. In addition, Kinex automatic liquid fillers are particularly well suited for filling tinctures, reagents, essential oils, pharmaceuticals and other applications in which the prevention of cross contamination is critical.
Fully Automatic Bottle Filling, Capping & Shrinking Machine The bottle Rinsing (Manual), Filling & Capping Machine is fully automatic to pack the treated water inPET Bottles.
Technical Parameters for 200ml to 2000ml Rinsing, Filling, Capping & Shrinking Machine.
| Model Number | AT –FAFM 40BPM |
| Production Capacity | 2400 Bottle/Hr |
| Filling Capacity | 200ml to 2000ml |
| Neck Description | Standard for full range |
| Voltage | 380V / 3 phase / 50 Hz |
| Total Power | 011 KW |
| Unit Dimensions (L X D X H) | 3000 X 2200 X 2150 |
| Max. Air Pressure | 0.4 M3/Min., 6-7 Bar |
| Stainless Still Grade | 316 for Product contact, all rest 314 |
| Rinsing & Washing Heads | 2 (Manual Type) |
| Filling Heads | 8 to 12 |
| Capping Heads | 1 |
| Structure | Monoblock |
| Bottle Type | PET Bottles Only (No Glass) |
Other General Features:
Ø New neck handling free suspension machines, helps to make bottles change over veryeasy, can change from one bottle size to another in matter of minutes
Ø All Full Stainless steel neck handling disc
Ø Inside and outside rinsing of Bottles
Ø Inside Recycle water tank to remove dirt
Ø Hot water for Wash cycle, with adjustable Heater temperature up to 60C
Ø Fully sealed units with large tempered glass windows for observation
Ø All transfer parts lower than filling valve
